Laser Safety Filter #0290 ONTOR

000-K0290-ONTO-54

Laser Safety Eyewear #0290 was developed for SiroLaser Blue by Dentsply Sirona in particular, covering blue diode (445nm), red diode (660nm) and infrared (970nm) in one eyewear, paired with a visual light transmission (VLT) of 29%. The laser safety filter is CE certified in accordance with the requirements of EN 207.

Please take care, if calculating the needed protection levels for your laser application, and match them with the protection levels on the laser safety eyewear. The employees of PROTECT-Laserschutz are looking forward to assist you by choosing the right safety equipment.

Protection level

Specifications Filter

Specifications Frame

Order Information

All available frames

The laser safety filter #0290 is available in the following frames.

Laser Safety Filter #0290 ONTOR

Wavelength (in nm)	Protection levels acc. to EN 207
315 - 380	D LB6 + IR LB8 (OD 8+)
380 - 460	DIR LB6 (OD 6+)
460 - 488	DIR LB5 (OD 5+)
488 - 498	DIR LB4 (OD 4+)
498 - 513	DIR LB3 (OD 3+)
513 - 526	DIR LB2 (OD 2+)
526 - 536	DIR LB1 (OD 1+)
650 - 670	DIR LB1 (OD 1+)
660 - 666	DIR LB2 (OD 2+)
670 - 676	DIR LB1 (OD 1+)
715 - 764	DIR LB1 (OD 1+)
764 - 801	DIR LB2 (OD 2+)
801 - 846	DIR LB3 (OD 3+)
846 - 897	DIR LB4 (OD 4+)
897 - 955	DIR LB5 (OD 5+)
955 - 1064	DIR LB5 (OD 5+)
	PF CE
